C2-26 Xianghe 164Q Receiver Filter Drier Φ76x165 5/8 Eco Port for Bus AC

The C2-26 Xianghe 164Q receiver filter drier is an integrated refrigeration purification component designed for medium and large bus air conditioning systems, with outer dimension Φ76×165mm and standard 5/8 environmental protection port. Different from ordinary single-function filter driers, it integrates liquid refrigerant storage and drying filtration, installed on the high-pressure liquid pipeline between condenser and expansion valve to stabilize refrigerant supply and continuously purify the whole refrigeration circuit.

Inside the sealed steel shell, it is filled with high-capacity molecular sieve desiccant and multi-layer stainless steel filter screen, which can fully absorb residual moisture in the refrigerant and intercept metal debris and pipeline dust generated by long-term system operation. Meanwhile, the large internal cavity stores excess liquid refrigerant to buffer flow fluctuation of refrigeration cycle, ensure stable liquid supply for expansion valve, and avoid insufficient cooling or system fluctuation caused by refrigerant volume change under different working conditions.
